1.Design Aesthetics: Ultra-narrow 60mm sash profiles maximize glass area, delivering uninterrupted panoramic views with barely-there frames.
2.Structural Capacity: Reinforced main profiles with 1.8mm-2.5mm wall thickness support spans up to 8 meters and single sash loads up to 200kg.
3.Hardware Performance: Precision-engineered stainless steel multi-point locking system ensures smooth folding operation, consistent compression, and forced-entry resistance.
4.Weather Resistance: Advanced equal pressure chamber and hidden drainage design, combined with EPDM compression seals, achieve Class 6 water tightness and Class 8 air tightness.
5.Application Versatility: Suitable for coastal villas, commercial spaces, and passive houses with tailored options for each environment.
6.Lifestyle Integration: Creates seamless indoor-outdoor living spaces that adapt to how families actually live and entertain.
7.Installation Efficiency: Pre-assembled hardware kits and coded extrusion profiles reduce on-site installation time significantly.
8.Sustainability: High-recycled-content aluminum profiles combined with 100% recyclable construction support circular economy principles.
9.Comparative Advantage: Offers 100% opening width versus 50% for sliders, and supports larger glass panels than standard bifold systems.
10.Global Compliance: Engineered to meet regional standards including AAMA, EN ISO 10077, AS 2047, and GB/T 8478.
Product Name | Aluminum Bi-Folding Door |
Profile | High Strength Aluminum Alloy |
Aluminum Material Grade | 6060-T66 |
Glass (Optional) | Fully Tempered / Low-E Coating / Argon Gas Filled |
Surface Treatment | Powder Coated Smooth Finished |
Adjustable Dimensions | After installation, 3-axis adjustment |
Customization Service | Full Custom Order |
Roller System | Smooth-gliding Heavy-Duty Nylon Rollers |
Certification | Complies with AS2047 Australian Standard |
Advantage | Heat Insulation / Waterproof / Soundproof |
FAQ
1.What folding patterns are supported?
It supports patterns like 2+2 and 4+4 and can integrate with corner posts.
2.Can it fit my unique layout?
Yes, flexible folding configurations and 90-degree corners adapt to your layout.
3.What are the sightline dimensions?
It is engineered with 62mm frame and 60mm sash visible widths.
4.How slim are the frames?
Ultra-narrow 60mm profiles put the focus on your view.
5.Is it good for home offices?
Sound-dampening glass and airtight seals create quiet workspaces.
6.Does it adapt to my lifestyle?
It moves with your rhythm—fold two panels for a breeze or four for a party.
7.Can glass be installed on site?
It accommodates both site-glazing and factory-glazing workflows.
8.Does it help with natural ventilation?
Multi-configuration folding allows cross-ventilation, reducing mechanical cooling.
9.How does it compare to custom solutions?
It delivers custom-fit performance with off-the-shelf efficiency.
10.Does it work in Nordic climates?
Triple-seal technology prevents ice formation and condensation in sub-zero conditions.
